10 mm Push‑Fit × ½″ BSP Straight Adaptor
Push-fit adaptor connecting 10 mm OD tubing (plastic or copper) to a ½″ BSP female thread.
Made from lead‑free, food‑grade acetal, suitable for potable liquids, air, gases, and vacuum use.
The John Guest PM011014E is a high-quality 10 mm push-fit × ½″ BSP straight adaptor from the John Guest PM range. Built using durable black acetal copolymer, it securely connects soft-metal or plastic tubing to ½″ female BSP-threaded components such as valves, pumps, and fittings.
Engineered for ease of use with instant push-fit connection, this adaptor provides a leak-tight seal without tools or sealant. The stainless steel collet and food-grade nitrile O‑ring ensure reliable, hygienic service.
Features & Benefits
-
Compatible with plastic or copper 10 mm OD tube
-
Lead-free, potable‑water safe
-
NSF‑61 listed, BBPA compliant
-
Fast push-fit connection/disconnection—no tools needed
-
Suitable for potable liquids, inert gases, compressed air, or vacuum systems
???? Technical Specification
-
Connection 1: 10 mm OD push‑fit (acetal)
-
Connection 2: ½″ BSP parallel male thread
-
Material: Acetal Copolymer body, EPDM/Nitrile O‑ring, Stainless Steel 301 collet teeth
-
Max Working Pressure: 10 bar (145 psi)
-
Max at 65 °C: 7 bar (100 psi)
-
Operating Temperature: 1 °C to 65 °C
-
Country of Origin: UK
✅ Applications
Ideal for converting between metric tubing and imperial BSP-threaded parts, commonly used in RO/DI filtration systems, vending/drinks dispense systems, potable water, and pneumatic setups.
| Size | 10mm |
|---|---|
| Fitting Type | Bsp Straight Adaptor |
