Liquid Logic Float Switch
Horizontal float switch which is mounted into the side wall on a tank.
When used with our range of our controllers, and fitted correctly, this float is a highly reliable for water shutoff and can be daisy-chained in sequence to create multiple cutoff points.
Recommended for use with the Liquid Logic range of controllers.
> Requires a clearance hole of 20.5mm hole.
> EPDM Rubber sealing gasket for the float body is included (recommended to be greased with Molycote Compound to ensure the gasket inserts correctly into the wall of the tank).
> Float is normalled installed so that the switch is normally closed. However by a 180 degree float rotation, the switch can be operated as normally open.
> 60°C Temperature range
> 5 BAR Maximum operating pressure.
> Maximum Switching Current 1.0
> Float is supplied with 2 x 0.2mm /22AWG 100mm length cables
