PRESSURE SWITCH FANAL 30-250 BAR
Contact 10 A - 380 V (Ac1)
Max 250 Bar
90°C
3/8" F
Height:140mm
Press:30-250 Bar
Type:Ff4-250
Upper switchpoint: 30 .... 250 bar
Lower switchpoint: 14 .... 226 bar
Smallest difference lower: 12 / 24 bar (upper / lower end of range)
Max.operating pressure: 400 bar
Max. test pressure: 500 bar
Standard setting: 100 / 200 bar
Connector G 3/8" stainle
| Bar | 250 |
|---|---|
| Length | 140mm |
| Inlet | 3/8" Female |
| Material | Plastic |
| Colour | Clear |
| Cleaning Temperature | 90 |
| Electrical Voltage | 380 V |
| M Number | 1010072 |
| M Number | FF4-250 PAH |
| Additional information | Contact 10 A - 380 V (Ac1) Max 250 Bar 90°C 3/8" F Height:140mm Press:30-250 Bar Type:Ff4-250 |
